| Size | PR | L.I. | S.R. | O.D.(mm) | T.D.(mm) | S.W.(mm) | RIM | Max.Load Capacity & Inflation Pressure | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Single | Dual | ||||||||||||||
| (kg) | (lbs) | (kPa) | (psi) | (kg) | (lbs) | (kPa) | (psi) | ||||||||
| 11R22.5 | 16PR | 146/143 | M | 1054 | 20.0 | 279 | 8.25 | 3000 | 6610 | 830 | 120 | 2725 | 6005 | 830 | 120 |
| 11R22.5 | 18PR | 149/146 | M | 1054 | 20.0 | 279 | 8.25 | 3250 | 7160 | 930 | 135 | 3000 | 6610 | 930 | 135 |
| 315/80R22.5 | 20PR | 157/154 | M | 1082 | 20.0 | 312 | 9.00 | 4125 | 9095 | 900 | 130 | 3750 | 8270 | 900 | 130 |
